HBS Double Bed Welding Positioner

Parameters of HBS Double Bed Welding Positioner

Model	HBS300	HBS600	HBS100	HBS1500
Rated Loading (kg)	30000	60000	100000	150000
Rotating Speed (rpm)	0.025-0.5	0.025-0.5	0.025-0.5	0.025-0.5
Tilting Speed (rpm)	0.1	0.1	0.1	0.1
Worktable Diameter (mm)	￠4000	￠5000	￠5000	￠5000
Max. Eccentricity (mm)	400	300	300	300
Max. Gravity Center Distance (mm)	1200	1800	2000	2000
Worktable Tilting Angle (°)	-45~+90	-45~+90	-45~+90	-45~+90
Rotating Motor Power (Kw)	11	22	18.5 × 2	30 × 2
Tilting Motor Power (Kw)	5.5 × 2	11 × 2	22 × 2	37 × 2

Double bed welding positioner is designed and manufactured for the purpose of obtaining higher stability and carrying capacity. This welding equipment is suitable for the welding of large-scale and heavy type work-piece. The maximum diameter of worktable can be 5000 mm. As a professional double bed welding positioner manufacturer and supplier in China, we also provide cutting equipment, CNC flame cutting machine, steel structure production line, H-beam welding line, box-beam production line, assembling machine, welding machine and welding wind tower production line.
